Aeromotive 5.0 GPM Brushless Gear Pump – Round External (P/N 11182)
Ground-Shaking Performance – Advanced Technology
Deliver reliable, high-output fuel flow with the Aeromotive 5.0 GPM Brushless Gear Pump – Round External. Built for extreme street and race applications, this pump features cutting-edge brushless technology, reduced current draw, and an all-new spur-gear pumping mechanism for unmatched durability and flow consistency.
⚙️ Horsepower Support (Flywheel HP)
Fuel Injected – Gasoline:
-
Up to 3,400 HP (Naturally Aspirated)
-
Up to 2,600 HP (Forced Induction)
Carbureted – Gasoline:
-
Up to 3,600 HP (Naturally Aspirated)
-
Up to 2,700 HP (Forced Induction)
Fuel Injected – E85:
-
Up to 2,380 HP (Naturally Aspirated)
-
Up to 1,820 HP (Forced Induction)
Carbureted – E85:
-
Up to 2,520 HP (Naturally Aspirated)
-
Up to 1,890 HP (Forced Induction)
Fuel Injected – Methanol:
Carbureted – Methanol:
? Performance Highlights
-
Brushless motor technology for long service life and reduced amperage draw
-
New spur-gear mechanism ensures precise and efficient fuel delivery
-
Continuous pressure: 90 PSI | Peak pressure: 150 PSI (base + boost)
-
Rated EFI flow: 1,700 lbs./hr. @ 40 PSI, 13.5V
-
Rated Carb flow: 1,850 lbs./hr. @ 9 PSI, 13.5V
-
External brushless controller for cooler fuel and easy installation
-
ORB-12 inlet / ORB-10 outlet for maximum fuel volume
-
Compact and lighter than traditional external-mount pumps
-
Compatible with gas, E85, and methanol (reduced flow on E85 and methanol)
⚠️ Important Notes
-
Requires regulated 12V–16V DC power supply
-
Not compatible with 16V charging systems (16–18V) without a voltage step-down
-
Not for use with pulse-modulated fuel systems or speed controllers
-
Emissions Notice: Not legal for use on emission-controlled vehicles unless replacing an OEM-spec part
Built to handle serious horsepower and extreme pressure, the Aeromotive 5.0 GPM Brushless Gear Pump is the ultimate external solution for high-demand fuel systems.
