Aeromotive 100 Micron Extreme Flow Fuel Filter with AN-16 ORB Ports & Stainless Mesh Element

P/N 12362: Extreme Flow 100-m SS AN-16 ORB Fuel Filter
Max flow filtration for Brushless Gear and Mechanical Fuel Pumps

High-flow Stainless Steel filter ideal for broad fuel applications including Alcohol Methanol, Ethanol, Gasoline and Diesel fuel using mechanical or electric fuel pumps up to 32-GPM.

This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

Suitable prefilter with mechanical or electric pumps up to 12-GPM.  Suitable post filter for mechanical injection systems up to 32-GPM mechanical pumps.

• High-flow, 100-micron Stainless Steel cleanable element.


• Ideal for Gasoline, Alcohol Methanol, Ethanol and Diesel fuels.


• Prefilter for up to 12-GPM mechanical or electric fuel pumps.


• Post filter for 32-GPM mechanical fuel injection systems.


• Flows 6,000 lb/hr (12-GPM) with a pressure drop under 1-PSI.


• Flows 12,000 lb/hr (32-GPM) with a pressure drop of 2-PSI.


• AN-16 ORB ports. Fittings available to adapt these filters from AN-16 down to AN-08 line sizes. (see Fittings & Adapters).


• Extreme-Flow filters feature a tough, Hard-Coat Black finish.


• 10" long x 2-5/8" diameter.


• Replacement element P/N 12662
